Glare Free Inflatable Lighting Balloon Mountable On Pavement Machine Vehicle

Glare free lighting balloon mountable on pavement machine vehicle 400w~2000W 120/230V

SUN™ BALLOON LIGHT

Our tubular balloon envelope diffuser distribute the light evenly in all directions and it also enjoys high luminance penetration rate, optionally of M1 rated fire retardant fabric.

Sun series balloon light is mainly intended for specific application in construction, industrial, safety & rescue etc. industries. Sun series is our specialty air-inflated balloon light integrating latest lighting technologies - LED and conventional light sources - tungsten halogen, metal halide or film grade HMI lamps, aiming to provide very different and wide applications in environments requiring glare free.

Above video: Sun series LED 400w glare free balloon lighting for industrial illumination, working at 90~265VAC mains power or AC 1kVA portable generator, emitting over 40,000 lumens

GENERAL FEATURES

1) Air-inflated balloon structure with special fabric, with or without internal reflector

2) Primarily for tripod stand mount, pole mount, equipment mount etc .application

3) Indoor or outdoor use

4) Different efficient light source available - Tungsten (HA), LED, HID (HMI / metal halide)

5) Start and work directly - tungsten or with electrical ballast (HID)or drive (LED). A battery work mode is available at its Direct Current version.

Sun™ has 3 standard ranges:

• Sun portable - 80w~400w. Lighted area (>1 lx): 360m²/3,875ft² ~ 1,760m²/18,940ft²;
  dia. 45cm~90m x H30~60cm. Either on mobile generator (<0.6kVA) or battery (12v/24v/48v), for mobile site, camp, rescue & emergency use etc.
• Sun Ex - 2,000w~4,800w. Lighted area (>1 lx): 5,820m²/62,646ft² ~ 20,000m²/215,278ft²;
  dia. 90cm~130m x H60~110cm. AC power work mode. Mainly for event or large area (>5,000sqm) illumination

Besides, Sun could also be classified into below categories on light source and control versions:

• Sun Tungsten halogen - 650~4,000w;
• Sun LED (white 3000k/6500k optional) - 60w~600w; custom 800w~1,200w;
• Sun MH (metal halide) - 150w~4,000w;

FUNCTIONS

1) lighting/illumination

2) signal

APPLICATIONS

1) Construction
2) Safety & rescue, firefighting, police check point etc.
3) All kinds of event outdoor illumination
4) Camping
5) Military

ill

FEATURED PRODUCTS

• Sun MH150 / Sun MH400 / Sun MH1000;
• Sun MH3000
• Sun HMI575 / Sun HMI1200
• Sun HMI4800
•

• Product Model:
• Sun™ LED400

• Functions:
• lighting (main/supplementary)

• Market:
• Event, Construction, Emergency, Rescue

• Place:
• Golf course, square, construction site, roadway etc.

• Theme:
• Night activities, outdoor sports, concert, parking lot etc.

• Technical data:
• light source: LED (restrike: instant)
  supply voltage: AC 120/230V or special
  power: 480w
  luminance: 40,000lm
  color temp. 6500k
  ref. lighted area: 10lx - 450sqmtr/4,843sqft; 1lx - 1,350sqmtr/14,530sqft
  envelope shape: sphere / dia.70cm x 36cm

• Description:
• This product is an economic solution for outdoor medium area (500~1000 square meter) illumination.
  It is suitable at golf, stadium, square, parking lot etc. assembly locations, as main or supplementary lighting purpose, meanwhile for event theme decoration and guidance etc.

• Options:
• envelope variation (tubular or ellipse) and custom etc.
  lighting dimmable (power output 50%~100%)
  remote control
  DMX512 control (on/off)
  mounting options: tripod, pendular, affixing etc.
