Stainless Steel IP44 Grid Connected Power Distro Box

Stainless Steel IP44 Grid Connected Power Distro Box

    • Stainless Steel IP44 Grid Connected Power Distro Box
    • Stainless Steel IP44 Grid Connected Power Distro Box
    • Stainless Steel IP44 Grid Connected Power Distro Box
    • Stainless Steel IP44 Grid Connected Power Distro Box
  • Stainless Steel IP44 Grid Connected Power Distro Box

    Product Details:

    Place of Origin: China
    Brand Name: Chint
    Certification: CE,CCC
    Model Number: XL-21, JXF, GGD

    Payment & Shipping Terms:

    Minimum Order Quantity: 1 Unit
    Price: USD20~USD200
    Packaging Details: Standard export carton/crate wood box
    Delivery Time: 5-8 working days or bulk order negotiate
    Payment Terms: T/T, Western Union
    Supply Ability: 300pcs/month
    Contact Now
    Detailed Product Description
    Material: Stainless Steel Color: White RAL 7035
    Application: To Protect Circuit Breakers Installed In The Panel Box,Indoor Or Outdoor,Industrial Type: Distribution Box,Power Distribution System
    Protection Level: IP44 Standard: IEC60439-3
    Function: Waterproof Distribution Box Certification: CE
    Working Temperature: -40 To +50 Degrees Centigrade Name: Distribution Cabinet/Power Electric Meter Box
    High Light:

    Grid Connected power distro box

    ,

    IP44 power distro box

    ,

    Stainless Steel Power Distro Box

    XL21 Chint Motor Control Center JXF Enclosure in Sheet Steel for Power Distribution or Water Pump Control Cabinet

    Panel Building Services for Electrical Installation and Distribution



    General:

    XL21 type AC low voltage distribution cabinet is suitable for power distribution system with 50Hz AC, rated working voltage 380V, rated working current up to 3150A for power users such as power plants, substations, factories and mining enterprises, as power, lighting and distribution equipment of power conversion, distribution and control. The products are characterized by high breaking capacity, good dynamic and thermal stability, flexible electrical scheme, convenient combination, series, strong practicability, novel structure, high protection level, etc. , the utility model can be used as a replacement product of low-voltage switchgear.

    XL21 AC low-voltage distribution cabinet conforms to IEC439"Low-voltage switchgear and control equipment", GB7251"Low-voltage switchgear"and other standards.



    An electrical enclosure is used to protect users from electric shock and electrical or electronic components from the environment. The manufacturers of the electrical enclosure not only concentrate on the safety aspect of it, but also on the attractiveness, to make the enclosure pleasing to the eye. The electrical enclosure can be used to mount switches, displays and knobs. Metals, plastics, stainless steel, carbon steel and aluminum are the materials used to manufacture the electrical enclosure. Customized electrical enclosure can be used for mass-produced equipment and on the other hand, standardized enclosure is used for low production equipment. Electrical enclosure is also used to protect electrical equipment such as transmitters, power distribution systems, power generators, etc.



    MODE DIMENSION MODE DIMENSION
    H(MM) W(MM) D(MM) H(MM) W(MM) D(MM)
    XL21 2020/15 200 200 150 XL21 6060/30 600 600 300
    XL21 2520/15 250 200 150 XL21 7050/15 700 500 150
    XL21 3020/15 300 250 150 XL21 7050/20 700 500 200
    XL21 3025/20 300 250 200 XL21 7060/20 700 600 200
    XL21 3030/15 300 300 150 XL21 7060/25 700 600 250
    XL21 3030/20 300 300 200 XL21 7060/30 700 600 300
    XL21 3030/25 300 300 250 XL21 8060/20 800 600 200
    XL21 4030/15 400 300 150 XL21 8060/25 800 600 250
    XL21 4030/20 400 300 200 XL21 8060/30 800 600 300
    XL21 4030/25 400 300 250 XL21 8080/20 800 800 200
    XL21 4030/30 400 300 300 XL21 8080/25 800 800 250
    XL21 4040/15 400 400 150 XL21 8080/30 800 800 300
    XL21 4040/20 400 400 200 XL21 10060/20 1000 600 200
    XL21 4040/25 400 400 250 XL21 10060/25 1000 600 250
    XL21 4040/30 400 400 300 XL21 10060/30 1000 600 300
    XL21 5030/15 500 300 150 XL21 10070/20 1000 700 200
    XL21 5030/20 500 300 200 XL21 10080/20 1000 800 200
    XL21 5030/25 500 300 250 XL21 10080/25 1000 800 250
    XL21 5040/15 500 400 150 XL21 10080/30 1000 800 300
    XL21 5040/20 500 400 200 XL21 10080/40 1000 800 400
    XL21 5040/25 500 400 250 XL21 100100/25 1000 1000 250
    XL21 5040/30 500 400 300 XL21 100100/30 1000 1000 300
    XL21 5050/20 500 500 200 XL21 12060/20 1000 600 200
    XL21 5050/25 500 500 250 XL21 12060/25 1000 600 250
    XL21 5050/30 500 500 300 XL21 12070/25 1000 700 250
    XL21 6040/15 600 400 150 XL21 12080/20 1000 800 200
    XL21 6040/20 600 400 200 XL21 12080/25 1000 800 250
    XL21 6040/25 600 400 250 XL21 12080/30 1000 800 300
    XL21 6040/30 600 400 300 XL21 12080/40 1000 800 400
    XL21 6050/15 600 500 150 XL21 120100/25 1200 1000 250
    XL21 6050/20 600 500 200 XL21 120100/30 1200 1000 300
    XL21 6050/25 600 500 250 XL21 120100/40 1000 1000 400
    XL21 6050/30 600 500 300 XL21 14060/40 1400 600 400
    XL21 6060/15 600 600 150 XL21 14080/40 1400 800 400
    XL21 6060/20 600 600 200 XL21 140100/40 1400 1000 400
    XL21 6060/25 600 600 250 XL21 140100/40 1400 1000 400
    More dimension information, please contact with us.
