| Place of Origin: | China |
| Brand Name: | Fenigal |
| Certification: | ISO, CE |
| Model Number: | 6000 watt PV Solar System |
| Minimum Order Quantity: | 1 unit |
|---|---|
| Price: | Negotiate |
| Packaging Details: | Standard export carton |
| Delivery Time: | 5-8 working days bulk order negotiate |
| Payment Terms: | T/T, Western Union |
| Supply Ability: | depend on quantity |
| Product Name: | 6000 Watt PV Solar System | Solar Panel Type: | Grade A Polycrystalline |
|---|---|---|---|
| Output Voltage (V): | 230/400V | Inverter: | Growatt Off-grid Inverter |
| Panel Power: | 10000W | Output Frequency: | 50/60HZ |
| Load Power (W): | 6-12KW | Solar Panel Max Power Voltage: | 51.2V |
| Solar Module Efficiency: | Mono Panel Upto 22%, Poly Panel Upto 19% | ||
| High Light: | Energy Storage Battery BYD Blade Cell,LiFePO4 Energy Battery Blade Cell,24.576 KWH BYD Blade Cell |
||
Flexible configuration
Safe and reliable
| Model |
SNE1228BL-LFP
|
SNE1843BL -LFP
|
SNE2457BL -LFP |
| Performance | |||
| Battery type | Lithium-iron phosphate (LiFePO4) | ||
| Nominal Battery Energy(KWH) | 12.28KWH | 18.43KWH | 24.576KWH |
| Nominal Capacity | 120AH | 120AH | 120AH |
| Nominal Voltage(V) | 102.4V | 153.6V | 204.8V |
| Operating Voltage Range(V) | 86.4V-115.2V | 129.6V-172.8V | 172.8V-230.4V |
| Module Number | 2 | 3 | 4 |
| Standard charging current(A) | 30A @ 25°C | ||
| Max. constant charging current(A) | 120A @ 25°C | ||
| Standard discharging current(A) | 60A @ 25°C | ||
| Max. discharging current(A) | 120A @ 25°C | ||
| Cell technology | BYD Blade Lithium-iron phosphate(LiFePO4) | ||
| Depth of discharge(DOD) | 80% | ||
| Design life | 5000times @80%DOD | ||
| Warranty | 5 years | ||
| Warranty Document Supplied | Yes | ||
| Compatible hybrid inverters | SNE6K -GA/SNE8K -GA/SNE10K -GA/SNE12K -GA or other hybrid inverters | ||
| Protection function | |||
| Protection | Over-temperature, over charge, under-voltage, over-current, short circuit alarm Function | ||
| Display and Communication | |||
| Display | The information of Battery, such as SOC, battery voltage and so on | ||
| Communication | CAN/RS485 | ||
| General Specification | |||
| Dimension (L*W*H)(MM) | 1171*179*600MM | 1171*179*900MM | 1171*179*1200MM |
| Weight(KG) | 118KG | 165KG | 215KG |
| Shipping state voltage(V) | 3.20~3.30V/CELL | ||
| Shipping status SOC | 20%~30% | ||
| Charging Temperature | -20~+50°C | ||
| Discharging Temperature | -30~+60°C | ||
| Short term storage ambient temperat | -20~+35°C(<3 months, 20%~60%SOC) | ||
| Long term storage ambient temperat | -20 ~+30°C(<1 year, 30%~60% SOC) | ||
| Max. operating altitude | 4,000m(Derating above 2,000m) | ||
| Protection degree | IP21,indoor installation | ||
| Relative humidity | 5%-95% | ||
| Cooling | Natural convection | ||
| Noise emission | <29 db | ||
| Certification | TUV/CE/IEC/UN38.3/UL1973 | ||
