Integrated / Split Ats Automatic Transfer Switch For Generator

Integrated / Split Ats Automatic Transfer Switch For Generator

    • Integrated / Split Ats Automatic Transfer Switch For Generator
    • Integrated / Split Ats Automatic Transfer Switch For Generator
    • Integrated / Split Ats Automatic Transfer Switch For Generator
    • Integrated / Split Ats Automatic Transfer Switch For Generator
  • Integrated / Split Ats Automatic Transfer Switch For Generator

    Product Details:

    Place of Origin: China
    Brand Name: Fenigal/OEM
    Certification: CE,CCC
    Model Number: FMQ1-100/2P

    Payment & Shipping Terms:

    Minimum Order Quantity: 1 unit
    Price: Negotiate
    Packaging Details: Standard export carton
    Delivery Time: 5-8 working days bulk order negotiate
    Payment Terms: T/T, Western Union
    Supply Ability: 10,000pcs/month
    Contact Now
    Detailed Product Description
    Max. Current: 3200A Max. Voltage: 220/380V
    Pole: 3P,4P Product Name: Dual Power Automatic Transfer Switch ATS
    Color: White Frequency: AC 50 Hz/60Hz
    Standard: IEC60947-6-1 Control Power Voltage: AC110V AC220V
    Transfer I-II Or II-I: 0.45s~1.2s
    High Light:

    ats automatic transfer switch for generator

    ,

    Split ats automatic transfer switch

    ,

    Integrated ats automatic transfer switch





    General





    FMQ1 series Automatic transfer switch mainly used for distribution or electromotor network, which under voltage 380V, rated voltage DC 220V, Rated current 16A-3200A.


    Main power and standby power or mutual standby power change over system or city power and generator group overload switch-over. At the same time, it can operated under un-frequency on and off circuit act as disconnector.

    Widely used at the field of important power supply site, which transport, distribution power supply system and automatization system. For fire protection,hospital,bank,building,etc, where doesn't allow power off.



    Conventional thermal current lth A
    SQ5 Series
    Rated current ln(A)
    63A
    80A
    100A
    Rated impulse withstand voltage Ui(A)
    500
    500
    500
    Dielectric strength(V)
    3000
    3000
    5000



    Rated Working current le(A)


    380A
    AC-31
    63
    80
    100
    AC-33
    40
    63
    80
    AC-35
    63
    80
    100


    220A
    DC-31
    63
    80
    100
    DC-33
    40
    63
    80
    DC-35
    63
    80
    100
    Motor power P(380V)kW
    30
    30
    32
    Rated breaking capbility(A Rms)AC33 380V
    500
    640
    800
    Rated making capability(A Rms)AC33 380V
    630
    800
    1000
    Rated short-current making capability lcm(kA peak value)
    10
    10
    10
    Electric durability
    COSφ=0.65 AC33
    2000
    2000
    2000
    Change-oner time
    I-0-II or II-0-I (s)
    1
    1
    1
    I-0 or II-0 (s)
    0.5
    0.5
    0.5
    Power wer consumption of electrical control
    24V(DC)(w)
    25
    25
    25
    Moment of operation(Nm)
    25
    25
    25





    Integrated / Split Ats Automatic Transfer Switch For Generator 0
    Integrated / Split Ats Automatic Transfer Switch For Generator 1
