| Place of Origin: | China |
| Brand Name: | Fenigal |
| Certification: | ISO, CE |
| Model Number: | 6000 watt PV Solar System |
| Minimum Order Quantity: | 1 unit |
|---|---|
| Price: | Negotiate |
| Packaging Details: | Standard export carton |
| Delivery Time: | 5-8 working days bulk order negotiate |
| Payment Terms: | T/T, Western Union |
| Supply Ability: | depend on quantity |
| Product Name: | 6000 Watt PV Solar System | Solar Panel Type: | Grade A Polycrystalline |
|---|---|---|---|
| Output Voltage (V): | 230/400V | Inverter: | Growatt Off-grid Inverter |
| Panel Power: | 10000W | Output Frequency: | 50/60HZ |
| Load Power (W): | 6-12KW | Solar Panel Max Power Voltage: | 51.2V |
| Solar Module Efficiency: | Mono Panel Upto 22%, Poly Panel Upto 19% | ||
| High Light: | Grade A BYD blade cell,51.2 V BYD blade cell,LiFePO4 Energy Storage Battery blade cell |
||
Flexible configuration
Safe and reliable
Convenient operation and maintenance
| Model | SNE5126LFP-BL | ||
| Performance | |||
| Battery type | BYD Blade Lithium-iron Phosphate (LiFePO4) | ||
| Battery energy(KWH) | 6.144KWH | ||
| Nominal Capacity(AH) | 120AH | ||
| Nominal Voltage(V) | 51.2V | ||
| Operating Voltage Range(V) | 43.2V-57.6V | ||
| Standard charging mode | Constant current charging (CC) | ||
| Standard charging current(A) | 30A @ 25°C | ||
| Max. constant charging current(A) | 120A @ 25°C | ||
| Charge limit voltage(V) | 60.8V | ||
| Standard discharging mode | Costant current discharging(CC) | ||
| Standard discharging current(A) | 30A @ 25°C | ||
| Max. discharging current(A) | 120A @ 25°C | ||
| Discharging cut-off voltage | 32V | ||
| Scalability | Max.6 strings in parallel | ||
| Depth of discharge (DOD) | 80％ | ||
| Design life | ＞10 years(25°C/77F) | ||
| Compatible hybrid inverters | SNE5K-D1/SNE6K-D1/SNE8K-D1SNE8K-DA | ||
| Protection function | |||
| Protection | Over-temperature, over charge, under-voltage, over-current, short circuit alarm Function | ||
| Display and Communication | |||
| Display | LED indicator | ||
| Communication | CAN/RS485 | ||
| General Spacification | |||
| Dimension(H*W*D) | 1112*443*118MM | ||
| Weight | About 46KG | ||
| Installation | Wall Mount | ||
| Shipping status SOC | 20%~30% | ||
| Charging Temperature | -20~ +55°C | ||
| Discharging Temperature | -30~ +60°C | ||
| Short term storage ambient temperature | -20~+35°C ( <3 months,20~60% SOC) | ||
| Long term storage ambient temperature | -20~+30°C ( <1 year,30~60% SOC) | ||
| Max. operating altitude | 4,000m(Derating above 2,000m) | ||
| Protection degree | IP21, indoor installation | ||
| Relative humidity | 5%-95% | ||
| Cooling | Natural cooling | ||
| Noise emission | ＜29db | ||
| Certificate | CE, UN38.3, UL | ||
