Chint NXM Molded Case Circuit Breaker 3 Pole 4 Pole NXM-63 125S 250S 400S 630S 380V 415V Icu up to 50kA

Chint NXM Molded Case Circuit Breaker 3 Pole 4 Pole NXM-63 125S 250S 400S 630S 380V 415V Icu up to 50kA

  • Chint NXM Molded Case Circuit Breaker 3 Pole 4 Pole NXM-63 125S 250S 400S 630S 380V 415V Icu up to 50kA
  • Chint NXM Molded Case Circuit Breaker 3 Pole 4 Pole NXM-63 125S 250S 400S 630S 380V 415V Icu up to 50kA
  • Chint NXM Molded Case Circuit Breaker 3 Pole 4 Pole NXM-63 125S 250S 400S 630S 380V 415V Icu up to 50kA
  • Chint NXM Molded Case Circuit Breaker 3 Pole 4 Pole NXM-63 125S 250S 400S 630S 380V 415V Icu up to 50kA
Chint NXM Molded Case Circuit Breaker 3 Pole 4 Pole NXM-63 125S 250S 400S 630S 380V 415V Icu up to 50kA
Product Details:
Place of Origin: China
Brand Name: Chint
Certification: CE, CB, KEMA/Dekra etc.
Model Number: NXM
Payment & Shipping Terms:
Minimum Order Quantity: 1 unit
Price: USD20~USD200
Packaging Details: Standard export carton
Delivery Time: 5-8 working days
Payment Terms: T/T, Western Union
Supply Ability: 1,000pcs/month
Contact Now
Detailed Product Description
Product Name: Mccb Moulded Case Circuit Breaker,Good Quality 3 Pole Tmax 100A Mccb Molded Case Circuit Breaker,compact NS 800A 1000A 1250A 1600A Mccb Molded Case Circuit Breaker Rated Voltage: 380V,380/400V,AC230/440/660,230/400V AC 50/60Hz
Rated Current: 25,25,32,40,50,63,80,100,125,160,200,250,315,350,400,500,630A Poles Number: 3,4,3P 4P
Breaking Capacity: 25-50kA Material: Plastic,High Standard Plastic Silver Copper,Nylon PA66
Installation: Fixed And Plug-in Standard: IEC 60947-2
High Light:

industrial type circuit breaker

,

molded case circuit breaker

Chint NXM Molded Case Circuit Breaker 3 Pole 4 Pole NXM-63 125S 250S 400S 630S 380V 415V Icu up to 50kA



The moulded case circuit breaker will provide protection for the circuit and equipment in case of overload, short circuit and under voltage condition occurred in the power distribution circuit. Besides, it can also provide protection of overload, short circuit and under voltage for the non-frequent start of motor.



Chint NXM Molded Case Circuit Breaker 3 Pole 4 Pole NXM-63 125S 250S 400S 630S 380V 415V Icu up to 50kA 0



Frame size:

NXM series moulded case circuit breaker: 63A, 125A, 160A, 250A, 320A, 400A, 630A, 800A, 1000A, 1600A

NXMS series electronic breaker: 160A, 250A, 320A, 400A, 630A, 1000A, 1600A

● Rated operational voltage: Ue (VAC): 400/415/690

● Breaking capacity code: S, H

● Number of poles: 2P, 3P, 4P

● Release type:

  • thermal magnetic fixed type;

  • magnetic adjustable type;

  • thermal magnetic adjustable type;

  • thermal and magnetic adjustable type;

  • electronic type.

● Installation method: Fixed type; pulg-in type



Chint NXM Molded Case Circuit Breaker 3 Pole 4 Pole NXM-63 125S 250S 400S 630S 380V 415V Icu up to 50kA 1



Features:

NXM MOULDED CASE CIRCUIT BREAKER

  • The brand-new electronic release Manage fault accurately Operate more efficiently and reliably

  • Built-in busbar temperature sensor, to control every aspect. Select the most suitable frame size, increase the product cost performance and reduce costs of using.

  • The brand-new electronic release, provide more accurate circuit protection. The all-new electronic release can deal with the hidden fault more accurately, with a more convenient parameters setting.

  • Dual insulation design, for a more convenient maintenance. Enhance the insulating capacity of the product, allowing the accessories installation, which make the maintenance more safe and efficient.

  • With a USB port for better human-machine interaction. Connected with PC devices through the USB port, lets you manage functions such as data reading, parameter setting, on-line detection and failure recording.

  • Absolute adaptability, with steady and reliable operation in extreme conditions. -35°C/+70°operating temperature range. Meets several applications requirements

Chint NXM Molded Case Circuit Breaker 3 Pole 4 Pole NXM-63 125S 250S 400S 630S 380V 415V Icu up to 50kA 2

Chint NXM Molded Case Circuit Breaker 3 Pole 4 Pole NXM-63 125S 250S 400S 630S 380V 415V Icu up to 50kA 3

Chint NXM Molded Case Circuit Breaker 3 Pole 4 Pole NXM-63 125S 250S 400S 630S 380V 415V Icu up to 50kA 4

Chint NXM Molded Case Circuit Breaker 3 Pole 4 Pole NXM-63 125S 250S 400S 630S 380V 415V Icu up to 50kA 5

Chint NXM Molded Case Circuit Breaker 3 Pole 4 Pole NXM-63 125S 250S 400S 630S 380V 415V Icu up to 50kA 6

Chint NXM Molded Case Circuit Breaker 3 Pole 4 Pole NXM-63 125S 250S 400S 630S 380V 415V Icu up to 50kA 7

SKU

NXM-400S/3300 400 A

Condition

New

Product Code

NM1-400S/3300 400 A

Current Rating

400 Amp

Voltage Rating

690 VAC

Number of Poles

3P

Short Circuit Braking Capacity (kA)

35 kA

Product Type

Product
