| Place of Origin: | China |
| Brand Name: | Schneider Electric |
| Certification: | CE, CCC etc. |
| Model Number: | Resi9 |
| Minimum Order Quantity: | 12pcs / 1doz. |
|---|---|
| Price: | USD4~50/unit |
| Packaging Details: | standard in carton box |
| Delivery Time: | 2~15days |
| Payment Terms: | T/T, Western Union |
| Supply Ability: | 100,000 pcs/month |
| Model: | Resi9 | Pole(s): | 1,2,3,4, 1P+N |
|---|---|---|---|
| Volt: | 220~240VAC, 380~400VAC | Hz: | 50~60Hz |
| Phase: | 1/3 | Standard: | EN/IEC60898 |
| Certification: | CCC, CE, GS Etc. | Breaking Capacity: | Ics=Icn=6000A |
| Thermal Trip Curve: | C,D | Case Material: | Nylon 66 Recylable |
| Wiring: | Terminal Block, Busbar Duct Etc. IP20B | Electric Shock Protection: | Class II |
| Mechanical Life: | 20,000 | Electrical Life: | 10,000 |
| High Light: | industrial type circuit breaker,electric circuit breaker |
||
Resi9 series household circuit breaker
Schneider Electric's first miniature circuit breaker for retail channels
Schneider Electric Original Made In China
characteristic
High-quality profiles, green and environmental protection: all parts meet EU REACH, RoHS standards
The high torque design can withstand 2 times the national standard. The torque link is more reliable, and the installation is more secure.
Strict quality management, protection parameters are better than national standards: better than national standard, double safety
Mechanical life is 20,000 times, electrical life is >10000 times, insulation voltage is 500 volts; extreme environment, easy response
No fear of cold and heat, applicable temperature -35 ° C ~ +70 ° C, electric shock protection level II
Advantage
The module design is comprehensive, effectively dealing with short circuit, overload, leakage and overvoltage faults, protection circuit and the use quality and life of expensive appliances
The professional and powerful core structure is well designed and the materials are excellent.
The protection parameters are better than the national standard requirements, achieving reliable protection
Designed with a sleek look, chic handles and comfortable touch
Based on Schneider Electric's innovative fifth-generation technology platform, it is safer, more beautiful, more flexible and more efficient.
application
Household miniature circuit breaker
|
Product Series |
Resi9 |
|---|---|
|
product name |
Resi9 MCB |
|
product type |
Miniature Circuit Breaker |
|
Applications |
Power distribution protection |
|
Trip unit type |
Thermal magnetic |
|
Isolation function |
Be applicable |
|
colour |
white |
|
Leakage current protection |
Integrated leakage protection |
|
Product short name |
Resi9 MCB |
|---|---|
|
Number of poles |
1P |
|
Number of protection poles |
1 |
|
Rated current [In] |
16 A on 30 °C |
|
Network Type |
AC |
|
Network frequency |
50/60 Hz |
|
Rated working voltage [Ue] |
230 V AC 50/60 Hz |
|
Trip curve |
C |
|
Magnetic switch trip limit |
5...10 x In |
|
Breaking capacity |
6 kA Icn on 230 V AC 50/60 Hz in accordance with GB 10963.1/IEC 60898-1 |
|
Use breaking ability [Ics] |
36 kA 75 % Icu on...12...60 V AC 50/60 Hz in accordance with IEC 60947-2 |
|
Current limit |
3 in accordance with IEC 60898-1 |
|
Rated insulation voltage [Ui] |
500 V AC |
|
Rated impulse withstand voltage [Uimp] |
4 kV |
|
Use category |
AC class |
|
Contact position indication |
Have |
|
Control type |
handle |
|
Local signal indication |
On/off indication |
|
Installation type |
Locking clip locking |
|
Installation method |
35 mm DIN rail |
|
Width (multiple of 9mm) |
2 |
|
height |
94 mm |
|
width |
17.7 mm - 0.10...0.25 mm |
|
depth |
78.5 mm |
|
product weight |
0.125 kg |
|
Mechanical life |
20000 times |
|
Electrical life |
10,000 times |
|
Overvoltage category |
IV |
|
Wiring ability |
Screw (terminal) - 1...25 mm2 - rigid / flexible |
|
Stripping length |
14 mm |
|
Tightening torque |
2.5 Nm terminal |
|
Maximum output torque |
5.1 Nm |
|
standard |
GB 10963.1 |
|---|---|
|
certified product |
CCC is RoHS compliant |
|
IP protection level |
IP20 (open class (no chassis)) in accordance with IEC 60529 |
|
Electric shock protection level |
Class II |
|
Pollution level |
3 |
|
Moisture resistance |
2 in accordance with IEC 60068-1 |
|
Relative humidity |
95 % on 55 °C |
|
Ambient temperature |
-35...70 °C |
|
Storage ambient temperature |
-40...85 °C |
