Residual Current 1~100A Industrial Circuit Breaker ABB GSH RCCB RCD 2P 3P 4P 1P+N

Residual Current 1~100A Industrial Circuit Breaker ABB GSH RCCB RCD 2P 3P 4P 1P+N

  • Residual Current 1~100A Industrial Circuit Breaker ABB GSH RCCB RCD 2P 3P 4P 1P+N
  • Residual Current 1~100A Industrial Circuit Breaker ABB GSH RCCB RCD 2P 3P 4P 1P+N
  • Residual Current 1~100A Industrial Circuit Breaker ABB GSH RCCB RCD 2P 3P 4P 1P+N
  • Residual Current 1~100A Industrial Circuit Breaker ABB GSH RCCB RCD 2P 3P 4P 1P+N
Residual Current 1~100A Industrial Circuit Breaker ABB GSH RCCB RCD 2P 3P 4P 1P+N
Product Details:
Place of Origin: China
Brand Name: ABB
Certification: CE, CCC etc.
Model Number: GSH201, GSH202, GSH204
Payment & Shipping Terms:
Minimum Order Quantity: 12pcs / 1doz.
Price: USD6~80/unit
Packaging Details: standard in carton box
Delivery Time: 2~15days
Payment Terms: T/T, Western Union
Supply Ability: 100,000 pcs/month
Contact Now
Detailed Product Description
Model: GSH201, GSH202, GSH204 Pole(s): 2,3,4, 1P+N
Volt: 220~240VAC, 380~400VAC Hz: 50~60Hz
Phase: 1/3 Standard: EN/IEC60898
Certification: CCC, CE, GS Etc. Breaking Capacity: Ics=Icn=6000A
Thermal Trip Curve: B,C,D Case Material: PC Thermal Formed
Wiring: Terminal Block, Busbar Duct Etc. IP20B Electric Shock Protection: Class II
Mechanical Life: 20,000 Electrical Life: 10,000
High Light:

industrial type circuit breaker

,

electric circuit breaker

ABB GSH RCCB,RCD - Residual Current Circuit Breaker 1~100A, 2P,3P,4P,1P+N for electrical distribution IEC 61009





ABB Brand Original Made In China



RCD - residual current action protector

Personnel and equipment protection unit


ABB offers customers a complete range of residual current operated protectors, including residual current operated circuit breakers without overcurrent protection (RCCB-F200 series), residual current operated circuit breakers with overcurrent protection (RCBO-GSH200/GSN201/ GS201/DS201/F500 series), residual current operation protection module (RCD blocks-GDA200/DDA200 series), ground fault relay (DIN rail and panel mounting-RD/ELR series), etc., effectively protect workers from electrical contact damage. Protection performance in accordance with IEC/EN 61008 or IEC/EN 61009 for residential, commercial and industrial applications.


Customer benefit

  • Excellent product quality and a variety of international certifications

  • Complete range of products for industrial and residential applications

  • Provides universal accessories for System pro M Compact

Main characteristics

  • Supports all types of residual current protection (AC, A, B, AP-R)

  • Reliable design to prevent accidental tripping

  • Rated current up to 100 A

  • 0.01 A to 2 A Multiple sensitivity options

RCBO - residual current operated circuit breaker with overcurrent protection

Ensure high efficiency and reliable protection

RCBO is primarily intended for applications that require both overcurrent protection (overload and short circuit) and ground fault current protection.

The RCBO can detect faults and trip in time to ensure the safety of workers and equipment.

Customer benefit

  • high quality

  • Complete product range:
    – GSH200 electronic residual current operated circuit breaker
    – GSN201 electronic single-modulus 1P+N residual current operated circuit breaker
    – GS201 electronic dual-modulus 1P+N residual current operated circuit breaker
    – DS201 electromagnetic dual-modulus 1P+N residual current operated circuit breaker
    – F500 electromagnetic residual current operated circuit breaker

Main characteristics

  • Supports all types of residual current protection: AC, A, B, AP-R

  • Multiple breaking capacity for residential and industrial applications

  • Rated current up to 63 A, user-defined pole count for single or three phase grid

  • Rated residual current from 10 to 1000 mA



GSH201 AC-C63/0.03

General Information

  • Extended Product Type:

    GSH201 AC-C63/0.03

  • Product ID:

    2TAZ220111R2634

  • EAN:

    6940342285403

  • Catalog Description:

    GSH201 AC-C63/0.03 - RCBO

  • Long Description:

    Residual Current Circuit Breaker with Overcurrent Protection GSH201 AC-C63/0.03



    Technical

    • Standards:

      IEC 61009
      GB 16917

    • Type of Residual Current:

      AC type

    • Number of Poles:

      1+N

    • Number of Protected Poles:

      1

    • Rated Current (In):

      63 A

    • Rated Residual Current:

      30 mA

    • Rated Short-Circuit Capacity (Icn):

      6 kA

    • Tripping Characteristic:

      C

    • Position of Neutral Terminals:

      Right

    Technical UL/CSA

    • Short-Circuit Current Rating (SCCR):

      30 mA

    Dimensions

    • Product Net Width:

      69 mm

    • Product Net Height:

      0.085 m

    • Product Net Depth / Length:

      70 mm

    • Product Net Weight:

      0.185 kg

    Ordering

    • Minimum Order Quantity:

      1 piece

    • Customs Tariff Number:

      85363010

    GSH204 AC-C63/0.03

    General Information

  • Extended Product Type:

    GSH204 AC-C63/0.03

  • Product ID:

    2TAZ222401R2634

  • EAN:

    6957625385972

  • Catalog Description:

    GSH204 AC-C63/0.03 - RCBO

  • Long Description:

    Residual Current Circuit Breaker with Overcurrent Protection GSH204 AC-C63/0.03

    Technical

    • Standards:

      IEC 61009
      GB 16917

    • Type of Residual Current:

      AC type

    • Number of Poles:

      4

    • Number of Protected Poles:

      4

    • Rated Current (In):

      63 A

    • Rated Residual Current:

      30 mA

    • Rated Short-Circuit Capacity (Icn):

      6 kA

    • Tripping Characteristic:

      C

    • Position of Neutral Terminals:

      Right

    Technical UL/CSA

    • Short-Circuit Current Rating (SCCR):

      30 mA

    Dimensions

    • Product Net Width:

      125 mm

    • Product Net Height:

      0.093 m

    • Product Net Depth / Length:

      89 mm

    • Product Net Weight:

      0.74 kg

    Ordering

    • Minimum Order Quantity:

      1 piece

    • Customs Tariff Number:

      85363010

Residual Current 1~100A Industrial Circuit Breaker ABB GSH RCCB RCD 2P 3P 4P 1P+N 0





Residual Current 1~100A Industrial Circuit Breaker ABB GSH RCCB RCD 2P 3P 4P 1P+N 1

Residual Current 1~100A Industrial Circuit Breaker ABB GSH RCCB RCD 2P 3P 4P 1P+N 2
