Thql Industrial Circuit Breaker

Thql Industrial Circuit Breaker

  • Thql Industrial Circuit Breaker
  • Thql Industrial Circuit Breaker
  • Thql Industrial Circuit Breaker
  • Thql Industrial Circuit Breaker
  • Thql Industrial Circuit Breaker
Thql Industrial Circuit Breaker
Product Details:
Place of Origin: China
Brand Name: Fenigal/OEM
Certification: CE, CCC etc.
Model Number: THQL white
Payment & Shipping Terms:
Minimum Order Quantity: 12pcs / 1doz.
Price: Negotiate
Packaging Details: standard in carton box
Delivery Time: 2~15days
Payment Terms: T/T, Western Union
Supply Ability: 200,000 pcs/month
Contact Now
Detailed Product Description
Model: THQL White Pole(s): 1,2,3
Volt: 220~240VAC, 380~400VAC Hz: 50~60Hz
Phase: 1/3 Standard: EN/IEC60947
Certification: CCC, CE, GS Etc. Breaking Capacity: 3000A
Thermal Trip Curve: C Case Material: Nylon 66 Recylable
Wiring: Terminal Block, Busbar Duct Etc. IP20B Electric Shock Protection: Class II
Mechanical Life: 10,000 Electrical Life: 4,000
High Light:

10kA thql circuit breaker

,

230V thqp circuit breaker

Professional Factory Tql Thqc Thqp Thql Circuit Breaker, 10kA 230V/400V factory direct supply OEM

THQL Series Mini Circuit Breaker

White Black

Function
For protection against overload and short circuits in the electrical distribution system
Use in domestic, commercial and light industrial installations.
Specifications
Item Name: NEW THQL
Standard: IEC60898, BS 3871-PT1
Product Certifications: CE, ISO9001
Product Function: Short circuit protection, Over current protection
Number of Poles: 1P, 2P, 3P
Rated Current(A): 6A,10A,16A,20A,32A,40A,50A,63A
Rated Voltage(V): 120, 120/240, 240/440V AC
Rated Frequency: 50/60Hz
Breaking Capacity: 10KA
Electrical Life(times): No less than 6000 operations
Mechanical Life(times): (o-c)No less than 20000 operations
Protection Degree: IP20

Number of Poles 3P
Rated current (A) 30(6-100A)
Rated Voltage (V) 120 (1P), 120/240 (2P), 240/415 (3P)
Breaking Capacity (A) 3000
Electrical Life (Times) 6000

Mechanical Life (Times) 14000

Rated frequency 50/60Hz

Degree of protection IP20

Application THQL series miniature circuit breaker applies to industrial, commerical, lighting and electric machine distribution system with AC415V, 50/60Hz, rated working current up to 100A to protect against overload and short circuit. The item is installed into plug-in type mounting base.

Product name : Mini Circuit breaker
Item : THQL
Mounting type: plug in
Mini circuit breaker ,miniature circuit breaker,mcb
voltage: 110V , 220V , 380V,415V
Current: 6A , 10A , 16A , 20A , 25A , 30A , 40A , 50A , 63A,100A
Pole: 1 pole , 2 pole, 3pole
Breaking capacity : 6 KA
Packing: 10pcs in one inner box ,200pcs in one master carton , 24 kgs, size 58x40x35cm

Product Type Poles
THQC 1P / 2P / 3P
THQP 1P / 2P / 3P
THQL 1P / 2P / 3P
BH 1P / 2P / 3P
BH-P 1P / 2P / 3P
SD

1P / 2P



Model NO.
THQL115
Poles Number
1
Type
Circuit Breaker
Function
Overcurrent Protection
Certification
ISO9001-2000, CE
Body Material
Nylon
Rated Current
6A,10A,16A,20A,32A,40A,50A,63A
Color
White
Rated Voltage
120, 120/240, 240/440V AC
Capacity
10ka
Rated Frequency
AC50/60Hz
Degree of Protection
IP20
Standard
Conform to IEC 60898, BS 3871-PT1
Pole
1p, 2p, 3p,4p
Trademark
Fenigal/OEM
Transport Package
120PCS/Carton
Specification
Class A Quality
Origin
China



Miniature Circuit Breakers (MCB) which can be used in low voltage electrical installations to protect conductors, switchgear, and electrical equipment in general against overload and short-circuit.

  1.Specifications
  Standard   IEC/EN 60898-1
Electrical
features
Rated current In A 1,2,4,6,10,16,20,25,32,40,50,63
Poles P 1,2,3,4
Rated voltage Ue V 220/380 230/400 240/415
Insulation voltage Ui V 500
Rated frequency Hz 50/60
Rated breaking capacity A 4500/6000/10000
Rated impulse withstand voltage(1.2/50) Uimp V 6000
Dielectric test voltage at ind. Freq. for 1min kV 2
Pollution degree   2
Thermo-magnetic release characteristic   B,C,D
Mechanical
features
Electrical life t 8000
Mechanical life t 20000
Contact position indicator   Yes
Protection degree   lP20
Reference temperature for setting
of thermal element C 30
Ambient temperature C From -5~+40
(with daily average < 35 )
Storage temperature C -25~+70
Installation Terminal connection type   Cable /Pin-type busbar
Terminal size top /bottom for cable mm2 25
  AWG 18~3
Terminal size top/bottom for busbar mm2 25
  AWG 18~3
Tightening torque N*m 2
  ln-Ibs 18

Mounting   On DIN rail EN 60715(35mm)by means fast clip device
Connection   From top and bottom








Thql Industrial Circuit Breaker 0
