Electrical Hds 10kv Outdoor CCC Power Distribution Cabinet

Electrical Hds 10kv Outdoor CCC Power Distribution Cabinet

  • Electrical Hds 10kv Outdoor CCC Power Distribution Cabinet
  • Electrical Hds 10kv Outdoor CCC Power Distribution Cabinet
  • Electrical Hds 10kv Outdoor CCC Power Distribution Cabinet
  • Electrical Hds 10kv Outdoor CCC Power Distribution Cabinet
Electrical Hds 10kv Outdoor CCC Power Distribution Cabinet
Product Details:
Place of Origin: China
Brand Name: Chint
Certification: CE,CCC
Model Number: XL-21, JXF, GGD
Payment & Shipping Terms:
Minimum Order Quantity: 1 Unit
Price: USD20~USD200
Packaging Details: Standard export carton/crate wood box
Delivery Time: 5-8 working days or bulk order negotiate
Payment Terms: T/T, Western Union
Supply Ability: 300pcs/month
Contact Now
Detailed Product Description
Material: Stainless Steel Type: Distribution Box,Power Distribution System
Protection Level: IP50 Rated Voltage: 220/380V,120V/240V
Standard: IEC60439-3 Rated Current: 6A-400A
Function: Waterproof Distribution Box Certification: CE
Working Temperature: -40 To +55 Degrees Centigrade Name: Distribution Cabinet/Power Electric Meter Box
Altitude: <=2000m
High Light:

CCC power distribution cabinet

,

10kv power distribution cabinet

,

10kv electrical distribution cabinet

XL21 Chint Motor Control Center JXF Enclosure in Sheet Steel for Power Distribution or Water Pump Control Cabinet

Panel Building Services for Electrical Installation and Distribution



General

Outdoors integrated distribution box - XL21 series is designed according to reformation requirements and operational experience of gird construction, based on the principle of security, economic, reasonable and reliable. It is a new type outdoors integrated distribution box with functions of power distribution, controlling, protection, reactive power compensation, power metering. At the same time the electric leakage protection can be added according to users' requirements. The product has several benefits: novel structure, reasonable, high protection grade, convenient installation, debugging, maintenance and repair, etc. The product conforms to standard GB7251.1-1997, and passed 3C certification. It is the ideal low-voltage apparatus in reformation of power grids. Outdoors integrated distribution box - JP series is suitable for 0.4 kV voltage grade of power distribution, metering , protection and automatic reactive power compensation.


Main Performance:
1. Response rapidly, compensation effect is good, reliable work, leakage protector can be added according to customers' requests;
2. Protection functions: over-pressure, overload, under-pressure, under-current, short circuit, lack of phase, zero sequence overrun, etc;
3. automatic functions: power outages after launch, 10s automatic recovery after sending;
4. Improves the power factor of gird above 0.95.



Technical Data



Environmental temperature -40ºC~+55ºC
Relative air humidity ≤90% (relative environmental temperature is 20ºC~25ºC)
Altitude no more than 2000 m
Environmental conditions suitable for the casing installation, not suitable for places with fire and explosion danger, serious foul, chemical corrosion and strong vibration
Installation location the inclination to the vertical of the ground is no more than 5 degrees



Rated voltage 400 V
Rated frequency 50 Hz
Transformer capacity 30, 50, 63, 80, 100, 125, 160, 200, 250, 315 (kVA)
Capacitor grouping (in general) 2, 3, 4, 5; Can be adjusted according to customer's special requirements
Feeder circuit 3 roads generally, for each road, distribute according to its transformer's 40-60% of total capacity; Can be adjusted according to customers' special requirements
Compensation mode circulation cutting, coding cutting, fuzzy control automatic cutting
Control parameters reactive power or reactive current
Fastest response time 20 ms or less

Electrical Hds 10kv Outdoor CCC Power Distribution Cabinet 0Electrical Hds 10kv Outdoor CCC Power Distribution Cabinet 1Electrical Hds 10kv Outdoor CCC Power Distribution Cabinet 2Electrical Hds 10kv Outdoor CCC Power Distribution Cabinet 3Electrical Hds 10kv Outdoor CCC Power Distribution Cabinet 4Electrical Hds 10kv Outdoor CCC Power Distribution Cabinet 5
