230V Mini Track Type Ats Transfer Switch 2P 3P 4P 100A IEC 60947-6-1
Product Details
| Max. Current: | 100A | Max. Voltage: | AC 400V |
|---|---|---|---|
| Pole: | 2P,3P,4P | Rated Voltage: | 230V/400V |
| Rated Current: | 16A 25A 32A 40A 50A 63A 80A 100A | Product Name: | Dual Power Automatic Transfer Switch ATS |
| Frequency: | AC 50 Hz/60Hz | Operation Type: | Manual Operation 5000 Times |
| Standard: | IEC60947-6-1 | Switch Time: | <50ms |
| Highlight |
230v ats transfer switch,track ats transfer switch,IEC 60947-6-1 ats transfer switch |
||
Product Description
General
FMQ1-100/4P series automatic transfer switch is a new generation of the latest development products, ATS generally used to monitor the power supply circuits. When the power failure, ATS will changeover to backup power automatically, so that complete conversion power supply system.
At present, in particular suited for the important electricity power places where disallow to failure, in order to meet the needs of the scene, automatic switch has self-input and self-recover, self-input without self-recover, utility to utility, utility- generators work with a variety of functions, the product applied in 240V, AC 50Hz, rated current from 10A to 1250A(CB class) autocratically switch products.
Technical Datd
| Model type | FMQ1-100 |
| Rated working voltage | 220V AC 50Hz |
| Changeover time delay | 0.5s |
| Recovery delay | 0.5s~90s continuous resettable |
| Under voltage changeover value | 145V~210V continuous resettable |
| Overvoltage changeover value | 230V~300V continuous resettable |
| Changeover time | Less than 4s |
| Type | CB type |
| Pole | 3 pole, 4 pole |
| Certificate | CE, AAA |
Product Highlights
General FMQ1-100/4P series automatic transfer switch is a new generation of the latest development products, ATS generally used to monitor the power supply circuits. When the power failure, ATS will changeover to backup power automatically, so that complete conversion power supply system. At present...
