3000 Watt Off Grid CE Passed Home Solar Pv System
Product Details
| Certification: | ISO, CE | Application: | Home/Building/Apartment/Villa/Farm |
|---|---|---|---|
| System Name: | 3000w PV Solar System | System Voltage: | DC 48V |
| Watt Options: | 3000w/5000w/6000w/8000w/10000w | Inverter: | 3KW,built In Solar Controller |
| Water Resistance: | IP 65 | ||
| Highlight |
3000 watt home solar pv system,CE home solar pv system,home 3kw solar pv system |
||
Product Description
The Applications of the of grid system :
Solar power is an environmental friendly safe energy with abundant supply. Installing a on grid residential solar power system is a good way to meet the rising renewable energy portfolio standards.
With various level of governments' financial support for solar power system installation and feed -in-tariff for purchasing solar power feed into the grid, solar power system investment has become a risk-free financial product with a very attractive rate of return.
On Grid system is connecting to the national grid net directly. No battery backup.
On Grid system can only use at the country where allowed people connecting to the utility grid net.
It can be applied to the villa, household, tourist resorts, prairie areas, remote mountain village, no power supply areas, farms, villages, island, highway and any regions to generate electricity.
It can load household appliances like TV, Air Conditioner, refrigerator, lighting, washing machine, etc.
Technical Data
| Fenigal Off grid solar power system- SP3KW | |||
| System | Solar panel rated output power: 3000W | ||
| Basic Information | Suitable for daily power consumption : >18KWH | SP-3kw | |
| Allowable max loads power : 3KW(=4.2KVA) | |||
| Full set: | |||
| Total volume:1.96CBM | |||
| Total weight:537KG | |||
| Solar panel | FS300W mono solar panel(poly optional) | QTY | |
| Vmp:37.57V Voc:46.34V Imp 8.78A | 10pcs | ||
| Size : 1956*992*40mm | Connection | ||
| (Mono) ( poly) | 25 years life time (CE TUV) | ||
| Coated steel Glass:3.2mm Tem pered | TANFON advantage: | ||
| Terminal block:IP65 with MC4 connector | Training team and installation service | ||
| Efficiency performance :25 years 80 % 20 year 85% 10 years 90% | |||
| Connect way:each 2 pcs in series | |||
| PV combiner | Model:H6T-48V | QTY | |
| Simplify wiring between PV array and controller. Prevent hot spot effect | 1pc | ||
| thunderstorm& surge protection | |||
| Product Size:360*345*145mm | |||
| Hybrid solar Inverter | Wall type Inverter power:3kw/48V | QTY | |
| MPPT Controller model:48v/60A | 1pc | ||
| AC charger :10-15A | |||
| 100% USA brand MOS materials | |||
| Double protection, easy after sales service | |||
| O/P:110V,220VAC | |||
| Product size:473*270*108mm | |||
| Gel Battery | Capacity:12V/200AH | QTY | |
| full sealed Solar power gel battery, | 4pcs | ||
| Service life:6-8 years ,(free one for service) | |||
| Size:522*240*219mm | |||
| Connect way: 4pcs battery in series is each string. | |||
| panel rack | Slope Rooftop or Flat rooftop | QTY | |
| wind load:55m/s,snow load:1.5kn/m2 | 1set | ||
| structure:Anodized Aluminum+stainless steel, Angle adjustable | |||
| (other type of rack can be customized as per client's requirement ) | |||
| Cables | 1) 3pcs 16mm2*35CM battery cable | QTY | |
| 2pcs 16mm2*2M battery cable | 1set | ||
| 2)4mm2 PV cable 100M | |||
| 3)terminals and MC4+1P63A Battery switch | |||
