Cusomized 6000W Inverter CE IEC Grid Solar Voltaic System
Product Details
| Certification: | ISO, CE | Application: | Home/Building/Apartment/Villa/Farm/island |
|---|---|---|---|
| System Name: | 6000w PV Solar System | Output Voltage: | 230V/400V |
| Output Type: | Single Phase | AC Nominal Voltage: | 220V,230V,240V; 180Vac - 280Vac |
| AC Grid Frequency: | 50Hz/60Hz ±5Hz | Output Frequency: | 50Hz/60Hz ±5Hz |
| Highlight |
6000w solar voltaic system,ce solar voltaic system,iec solar voltaic system |
||
Product Description
The Applications of the of grid system :
1.Off-Grid Solar Power System is composed of solar panels, controller, inverter, battery bank, solar panel mounting racks, and other accessories required for a complete system.
2.This solar energy generating is mainly used for application with relatively-small power consumption, and the areas without grid-power network.
3.It's featured with high-efficiency, easy-installation, economic and environment-friendly, etc.
4.Auto-switch, self-recovery and unattended operation.
A.The system can provide electricity produced by solar energy to loads directly.
B.It can auotmatically select the solar energy or utility powerto charge the battery according to the state of the sunlight and battery voltage.
C.The systems can automatically identify the state of day and night, and interactive switches between AC mode and inverting mode at night.
Solar power is an environmental friendly safe energy with abundant supply. Installing a on grid residential solar power system is a good way to meet the rising renewable energy portfolio standards.
With various level of governments' financial support for solar power system installation and feed -in-tariff for purchasing solar power feed into the grid, solar power system investment has become a risk-free financial product with a very attractive rate of return.
On Grid system is connecting to the national grid net directly. No battery backup.
On Grid system can only use at the country where allowed people connecting to the utility grid net.
It can be applied to the villa, household, tourist resorts, prairie areas, remote mountain village, no power supply areas, farms, villages, island, highway and any regions to generate electricity.
It can load household appliances like TV, Air Conditioner, refrigerator, lighting, washing machine, etc.
Technical Data
|
Input Data (DC)
|
|||||
|
Max. recommended PV power
|
3900W
|
4680W
|
5460W
|
5980W
|
6500W
|
| (for module STC) | |||||
|
Max. DC voltage
|
500V
|
550V
|
550V
|
550V
|
550V
|
|
Start voltage
|
100V
|
100V
|
100V
|
100V
|
100V
|
|
PV voltage range
|
70V-550V
|
70V-550V
|
70V-550V
|
70V-550V
|
70V-550V
|
|
MPP work voltage range/
|
80V-550V /360V
|
80V-550V /360V
|
80V-550V /360V
|
80V-550V /360V
|
80V-550V /360V
|
| nominal voltage | |||||
|
Full load dc voltage range
|
160V-450V
|
190V-500V
|
150V-500V
|
160V-500V
|
175V-500V
|
|
Max. input current of tracker A/
|
10A/10A
|
10A/10A
|
15A/15A
|
15A/15A
|
15A/15A
|
| tracker B | |||||
|
Max. input current per string of
|
10A/10A
|
10A/10A
|
15A/15A
|
15A/15A
|
15A/15A
|
| tracker A/tracker B | |||||
|
Number of independent MPP
|
2/1
|
2/1
|
2/1
|
2/1
|
2/1
|
| trackers / strings per MPP tracker | |||||
|
Output (AC)
|
|||||
|
Rated AC output power
|
3000W
|
3600W
|
4200W
|
4600W
|
5000W
|
|
Max. AC apparent power
|
3000VA
|
3600VA
|
4200VA
|
4600VA
|
5000VA
|
|
Max. output current
|
13.6A
|
16.3A
|
19A
|
20.9A
|
22.7A
|
|
AC nominal voltage
|
220V/230V/240V;180Vac - 280Vac
|
220V/230V/240V
|
220V/230V/240V
|
220V/230V/240V
|
220V/230V/240V
|
|
AC grid frequency
|
50Hz,60Hz /±5Hz
|
50Hz/60Hz
|
50Hz/60Hz
|
50Hz/60Hz
|
50Hz/60Hz
|
|
Adjustable power factor
|
0.8leading...0.95lagging
|
0.8leading...0.8lagging
|
0.8leading...0.8lagging
|
0.8leading...0.8lagging
|
0.8leading...0.8lagging
|
|
THDi
|
<3%
|
<3%
|
<3%
|
<3%
|
<3%
|
|
AC connection
|
Single phase
|
Single phase
|
Single phase
|
Single phase
|
Single phase
|
|
Certificates and Approvals
|
CE, IEC62109, G83, VDE0126-1-1, UTE C 15-712,G59, AS4777, AS/NZS 3100, CEI0-21, VDE-AR-N4105, EN50438, CQC, IEC 61683, IEC 60068,
|
||||
| IEC 61727, IEC 62116, INMETRO | |||||
