1 Kw Off Grid Solar Panel Flat Roof Mounting System With Pro Inverter
Product Details
| Product Name: | 10000 Watt PV Solar System | Solar Panel Type: | Grade A Polycrystalline |
|---|---|---|---|
| Output Voltage (V): | 230/400V | Inverter: | Growatt Off-grid Inverter |
| Panel Power: | 10000W | Output Frequency: | 50/60HZ |
| Load Power (W): | 10kw | Solar Panel Max Power Voltage: | 47.13V |
| Solar Module Efficiency: | Mono Panel Upto 22%, Poly Panel Upto 19% | ||
| Highlight |
1kw solar panel flat roof mounting system,solar panel flat roof mounting system 1kw,pro inverter small pv system |
||
Product Description
General Introduction :
Solar power is an environmental friendly safe energy with abundant supply. Installing a on grid residential solar power system is a good way to meet the rising renewable energy portfolio standards.
With various level of governments' financial support for solar power system installation and feed -in-tariff for purchasing solar power feed into the grid, solar power system investment has become a risk-free financial product with a very attractive rate of return.
Protection functions: Multiple protections(low-voltage/over-voltage/over-load/short-circuit/overheat protection, self-recovery)
1.Off-Grid Solar Power System is composed of solar panels, solar inverter, battery bank, solar panel mounting racks, and other accessories required for a complete system.
2.This solar energy generating system is mainly used in power shortage, power instability, and no power areas.
3.It's featured with high-efficiency, easy-installation, economic and environment-friendly, etc.
4. With UPS and AVR voltage stabilizing function
5.Auto-switch, self-recovery and unattended operation.
Technical Data
|
No.
|
Component Name
|
Quan.
|
Unit
|
Model
|
Warranty
|
|
1
|
PV Module
|
30
|
pcs
|
280Poly-60
|
10 years and 25years
|
|
2
|
mounting structure,clamp,Screws
|
1
|
lot
|
Galvanized Steel or Alluminum Alloy
|
10 years
|
|
3
|
DC combiner box 5in1out
|
2
|
set
|
500V50A
|
2 years
|
|
4
|
OFF-Grid Inverter, 230VAC/50HZ
|
2
|
set
|
SPF5K
|
2 years
|
|
5
|
Battery and battery structure -30KWH,DOD 70%
|
24
|
set
|
2V900AH
|
2 years
|
|
6
|
PV Cable-Module to DC Combiner
|
400
|
m
|
1x4mm2
|
3 years
|
|
7
|
PV Cable-DC Combiner to Inverter
|
20
|
m
|
YJV 2x10mm2
|
3 years
|
|
8
|
Battery Cable-Inverter to Battery Box
|
20
|
m
|
BV/RVV1*25mm2
|
3 years
|
|
9
|
Battery Cable-Battery Box to Battery
|
30
|
m
|
BV/RVV1*50mm2
|
3 years
|
|
10
|
Battery Box (Breaker, SPD)
|
1
|
set
|
2in1out
|
2 years
|
|
11
|
AC Combiner Output Box, 2in 1 output
|
1
|
set
|
230V,50HZ, Breaker
|
3 years
|
|
12
|
AC Cables-Inverter to AC Combiner Output Box
|
10
|
m
|
YJV 3*4mm2
|
2 years
|
|
13
|
MC4 Connector
|
15
|
pair
|
MC4 Compatiable
|
3 years
|
|
14
|
PV TOOLS
|
1
|
set
|
|
|
|
According calculated based on an average daily sunshine time of 5 hours,The panel will generate 38kwh/day,The battery can storage 42kwh.
|
|||||
| Item | model | quantity |
| solar panel | 360w mono panel | 30 |
| pv combiner | H4T/240V pv combiner | 1 |
| solar controller | 50A/240V solar controller | 1 |
| solar inverter | 10kw/240v IGBT inverter | 1 |
| solar battery | 12v/200AH gel battery | 20 |
| mounting structure | on ground or on roof | 1 set |
| cables | 18pcs 16mm2*35cm battery cables&2pcs 16mm2*2M battery cables | 1 set |
| Connector | Rated Voltage:1000V | 1 set |
