8000w Commercial 48V Solar Photovoltaic System
Product Details
| Certification: | ISO, CE | Application: | Home/Industry/Commerical/Villa |
|---|---|---|---|
| System Name: | 8000w PV Solar System | System Voltage: | DC 48V |
| Watt Options: | 6000w/8000w/10000w | System: | Off Grid |
| Suitable For Daily Power Consumption: | >50.4kwh | Output Voltage: | 110V-240V Optional |
| Max Power: | Normal Inverter Power *120% | ||
| Highlight |
8000w solar photovoltaic system,solar photovoltaic system 8000w,48V solar photovoltaic system |
||
Product Description
The Applications of the of grid system :
Solar power is an environmental friendly safe energy with abundant supply. Installing a on grid residential solar power system is a good way to meet the rising renewable energy portfolio standards.
With various level of governments' financial support for solar power system installation and feed -in-tariff for purchasing solar power feed into the grid, solar power system investment has become a risk-free financial product with a very attractive rate of return.
On Grid system is connecting to the national grid net directly. No battery backup.
Technical Data
| Off grid solar power system- SP8KW | ||||
| System | Solar panel rated output power: 8400W | |||
| Basic Information | Suitable for daily power consumption : >50.4KWH | |||
| Allowable max loads power : 8KW(=11.4KVA) | SP-8kw | |||
| Full set: | ||||
| Total volume:3.6CBM | ||||
| Total weight:1310KG | ||||
| Solar panel | FS350W mono solar panel(poly optional) | QTY | ||
| Vmp:38.39V Voc:47.13V Imp 9.37A | 24pcs | |||
| (Mono) ( poly) | Size : 1956*992*40mm | |||
| 25 years life time (CE TUV) | ||||
| Coated steel Glass:3.2mm Tem pered | ||||
| Efficiency performance :25 years 80 % 20 year 85% 10 years 90% | TANFON advantage: | |||
| Connect way:each 4 pcs in series | Training team and installation service | |||
| PV Array Combiner | Model:H6T-96v Multiple PV strings inputs | QTY | ||
| and controller, Prevent hot spot effect | 1pc | |||
| Reliable thunderstorm& surge protection | ||||
| Product Size:400*425*145mm | ||||
| Solar Controller | MPPT controller model:96V/60A | QTY | ||
| Charging efficiency; 90%-95%, | 1pc | |||
| charging mode, intelligent control., | ||||
| various protection functions | ||||
| Pure sine wave Inverter | Inverter:8KW96VDC | QTY | ||
| 110V/120V/220V/230V/240VAC output, | 1pc | |||
| City power and generator charger build in Overload, overcharge, over-discharge protection | ||||
| Fuji brand IGBT material | ||||
| Gel Battery | Capacity:12V/150AH | QTY | ||
| full sealed Solar power gel battery, | 16pcs | |||
| Service life:6-8 years , | ||||
| Size:483*170*219mm | ||||
| Connect way: 8pcs battery in series is each string, | ||||
| 2 strings connect to solar hybrid inverter | ||||
| panel rack | Slope Rooftop or Flat rooftop | QTY | ||
| wind load:55m/s,snow load:1.5kn/m2 | 1set | |||
| structure:Anodized Aluminum+stainless steel, Angle adjustable | ||||
| (other type of rack can be customized as per client's requirement ) | ||||
| Cables | 1) 14pcs 16mm2*35CM battery cable | QTY | ||
| 4pcs 16mm2*1M battery cable | 1set | |||
| 2)4mm2 PV cable 200M | ||||
| 3)terminals and MC4+2P63A Battery switch | ||||
|
8000W home system Load reference
|
||||
| Load name | Load's watt | Qty | Total watt | |
| lights | 11W | 12 | 132 | This exemple is just for reference. But Your load can be less than 8kw |
| Fan | 80W | 4 | 320 | |
| Computer(LCD display) | 150W | 2 | 300 | |
| printer | 250W | 1 | 250 | |
| Fax machine | 150W | 1 | 150 | |
| refrigerator(200L) | 120W | 3 | 360 | |
| Washing machine | 300W | 1 | 300 | |
| Microwave | 1500W | 1 | 1500 | |
| Electric cooker | 300W | 2 | 600 | |
| Air conditioner(1.5HP) | 1125W | 3 | 3375 | |
| Satellite TV receiver/VCD | 25W | 1 | 25 | |
| Color TV(32 inch) | 150W | 2 | 300 | |
| Water pump | 200W | 1 | 200 | |
| Total | 7812 | |||
