CE ISO 6000w Residential Pv Wind Hybrid System
Product Details
| System Name: | 6000w PV Solar System | Application: | Home/Commercial |
|---|---|---|---|
| Voltage: | 111V~240V Including | Control Type: | Smart Switch Control |
| Certification: | CE ISO | Max Power: | Normal Inverter Power *120% |
| Highlight |
residential pv wind hybrid system,6000w pv wind hybrid system,6kw pv wind hybrid system |
||
Product Description
The Applications of the of grid system :
Complete Off grid tied Solar Power Generator/Solar Home Power System,SNAT would offer the system 300W to 50KW with good quality and fast transportation.Below SNAT Off grid solar home power system SNT-S 8000W only for reference,other type of systems can be customized as per client' s requirement.
Solar power is an environmental friendly safe energy with abundant supply. Installing a on grid residential solar power system is a good way to meet the rising renewable energy portfolio standards.With various level of governments' financial support for solar power system installation and feed -in-tariff for purchasing solar power feed into the grid, solar power system investment has become a risk-free financial product with a very attractive rate of return.
On Grid system is connecting to the national grid net directly. No battery backup.
Technical Data
| Off grid solar power system- SP8KW | |||
| System | Solar panel rated output power: 8400W | ||
| Basic Information | Suitable for daily power consumption : >50.4KWH | ||
| Allowable max loads power : 8KW(=11.4KVA) | SP-8kw | ||
| Full set: | |||
| Total volume:3.6CBM | |||
| Total weight:1310KG | |||
| Solar panel | FS350W mono solar panel(poly optional) | QTY | |
| Vmp:38.39V Voc:47.13V Imp 9.37A | 24pcs | ||
| (Mono) ( poly) | Size : 1956*992*40mm | ||
| 25 years life time (CE TUV) | |||
| Coated steel Glass:3.2mm Tem pered | |||
| Efficiency performance :25 years 80 % 20 year 85% 10 years 90% | advantage: | ||
| Connect way:each 4 pcs in series | Training team and installation service | ||
| PV Array Combiner | Model:H6T-96v Multiple PV strings inputs | QTY | |
| and controller, Prevent hot spot effect | 1pc | ||
| Reliable thunderstorm& surge protection | |||
| Product Size:400*425*145mm | |||
| Solar Controller | MPPT controller model:96V/60A | QTY | |
| Charging efficiency; 90%-95%, | 1pc | ||
| charging mode, intelligent control., | |||
| various protection functions | |||
| Gel Battery | Capacity:12V/150AH | QTY | |
| full sealed Solar power gel battery, | 16pcs | ||
| Service life:6-8 years , | |||
| Size:483*170*219mm | |||
| Connect way: 8pcs battery in series is each string, | |||
| 2 strings connect to solar hybrid inverter | |||
| panel rack | Slope Rooftop or Flat rooftop | QTY | |
| wind load:55m/s,snow load:1.5kn/m2 | 1set | ||
| structure:Anodized Aluminum+stainless steel, Angle adjustable | |||
| (other type of rack can be customized as per client's requirement ) | |||
| Cables | 1) 14pcs 16mm2*35CM battery cable | QTY | |
| 4pcs 16mm2*1M battery cable | 1set | ||
| 2)4mm2 PV cable 200M | |||
| 3)terminals and MC4+2P63A Battery switch | |||
