240V SM1L Moulded Case Circuit Breaker With Earth Leakage Protection
Product Details
| Model: | SM1L | Pole(s): | 1P+N |
|---|---|---|---|
| Volt: | 220/230/240V | Hz: | 50~60Hz |
| Phase: | 1/3 | Standard: | EN/IEC60898, IEC60947 |
| Certification: | CCC, CE, GS Etc. | Breaking Capacity: | Ics=Icn=6000A |
| Thermal Trip Curve: | C | Case Material: | Nylon PA6 Recyclable |
| Wiring: | Terminal Block, Busbar Duct Etc. IP20B | Electric Shock Protection: | Class II |
| Mechanical Life: | 20,000 | Electrical Life: | 10,000 |
| Highlight |
SM1L Molded Case Circuit Breaker,Earth Leakage Molded Case Breaker,240V Module Case Circuit Breaker |
||
Product Description
SM1L Series moulded case circuit breaker with earth leakage protection
Keyword:Vertical or Horizontal installation, with leakage current, alarm function;Leakage current tripping fast,
complete accessory and can adjust leakage operating current and time
Application
SM1L series moulded case circuit break with residual current pro-duction. Rated insulation Voltage is 800V. It applies to circuit of AC 50Hz, rated working voltage 400V and rated working Current up to 630A, for infrequent switch over and infrequent start of motor.
With overload,Short Circuit and under-voltage production,it can protect circuits and power-supply equipment from damage, can also be used for production from damage and any potential fire-hazard caused by long Existing earth fault which can not be detected by
over-current production. The value of residual current is selectable.
NB3LE MCB combines the following functions:
b Protection of circuits against short-circuit currents
b Protection of circuits against overload currents
b Control
b isolation
Specification Table
|
Standard |
Rated Current (A) |
Pole |
Voltage(V) |
Breaking Capacity(A) |
|
BS3871-1 IEC60898 |
10 to 40 |
1P+N |
230/240 |
6kA |
|
|
|
|
|
|
Operating conditions
● Ambient air temperature:-5℃ ~40℃
● Altitude:less than 2000 meters
● Greadient:less than 22.5°
● Place free from erosion of rain and snow
● Ambient environment/medium free from explosive danger and air or con- ductive dust
Function
● Overload protection
● Shunt circuit protection
● Under-voltage protection
● Residual current protection
● Power distribution
● Motor protection Disconnection
|
|
Standard |
|
IEC/EN 61009-1 |
|
Electrical |
Rated current In |
A |
6,10,16,20,25,32,40,50,63 |
|
poles |
|
1P+N,2P,3P,4P |
|
|
Rated voltage Ue |
V |
230/400 |
|
|
Insulation voltage Ui |
V |
500 |
|
|
Rated frequency |
Hz |
50/60Hz |
|
|
Rated breaking capacity |
KA |
6000 |
|
|
Rated impelse withstand voltage(1.2/50)UimpStandard |
V |
4000 |
|
|
Dielectric test voltage at ind,Fred,for 1 min |
KV |
2 |
|
|
Polluttion degree |
|
2 |
|
|
Themo-magnetic release characteristis |
|
B,C,D |
