Lockable Free Standing Enclosure Box Of Polyester SMC Fiber Glass Material

Lockable Free Standing Enclosure Box Of Polyester SMC Fiber Glass Material

  • Lockable Free Standing Enclosure Box Of Polyester SMC Fiber Glass Material
  • Lockable Free Standing Enclosure Box Of Polyester SMC Fiber Glass Material
  • Lockable Free Standing Enclosure Box Of Polyester SMC Fiber Glass Material
  • Lockable Free Standing Enclosure Box Of Polyester SMC Fiber Glass Material
  • Lockable Free Standing Enclosure Box Of Polyester SMC Fiber Glass Material
Lockable Free Standing Enclosure Box Of Polyester SMC Fiber Glass Material
Product Details:
Place of Origin: China
Brand Name: Fenigal/None
Certification: CE,CCC
Model Number: SMC
Payment & Shipping Terms:
Minimum Order Quantity: 1 Unit
Price: USD10~USD100
Packaging Details: Standard export carton
Delivery Time: 5-8 working days or bulk order negotiate
Payment Terms: T/T
Supply Ability: 1,000pcs/month
Contact Now
Detailed Product Description
Material: SMC/DMC Color: Grey White/Transparent Door
Application: Power Distributing Type: Distribution Box Electrical Boxes
Installation Type: Surface Type/ Flush Type Standard: IEC60439-3
Rated Voltage: 220V-380V,220/110V Rated Current: 32,63A,100A
Frequency: 50 HZ/60HZ External Size: 600x500x230mm
Working Temperature: -40 To +80 Degrees Centigrade
High Light:

Lockable Free Standing Polyester Enclosure Box

,

32A Fiberglass Polyester Enclosure Box

,

220V Fiberglass Enclosure Box

Lockable Free Standing Enclosure Box Made of Polyester SMC Fiber Glass Material

Product Description



  • This series cable distribution cabinets can be applied in rated frequency 50/60Hz and rated voltage 380V(660V) power system.

    It is used for power control and distribution of power , illumination and distribution devices. It is suited for kinds of harsh enviroments, substations ,industrial and mining establishments, urban roads, residential districts, high-rising buildings, airports and other outdoor public places. It is especially suited for petroleum,chemical adother causticity gas plants and high salt spray places(such as coastal area, island )



Product Application:



  • Electric power system
  • Construction building
  • Tender project



Product Advantage:



  1. SMC(Sheet Moulding Compound) is both a process and reinforced composite material .This is manufactured by dispersing long strands(>1") of chopped glass fibers on a bath of polyester resin .
  2. The longer glass fibers in SMC result in better strength properties than standard Bulk Moulding Compound(BMC) products .
  3. Typical applications include demanding electrical applications ,corrosion resistant needs ,structural components at low cost ,and automotive and transit applications .
  4. SMC has many good properties ,for example ,Fully insulated ,Corrosion resistance ,Anti-aging ,Heat resistance ,Impact resistance ,Flame retardant ,Anti-theft ,Light weight .







Place of Origin:
Zhejiang, China (Mainland)
Brand Name: WSELE/OEM
Model Number: DFX 6B Material: Glass fiber/SMC
Product Name:
SMC distribution box
Certificate: ISO9001,ISO14000,CCC,CE
Application: Electric power system OEM/ODM: Available



SMC meter box is made by craft of molding SMC unsaturated polyester resin, Fiberglass reinforced plastics. Its specialty has
solved the problem of wooden meter box, steel meter box and plastic meter box, such as easy to aging, rust, poor insulation
performance, poor cold resistance, poor fire resistance and short service life.
SMC is a hot press moulded advanced plastic composites used to produce SMC meter box, SMC electric junction box and other variety
of electrical products. These ranges of products are free from all the issues of rusting, denting, splitting, maintenance, etc.
Customized according to customer's request, complete accessories

Main Featrues
High strength yet light weight:
Helps save on transportation
Corrosion resistant:
Won't rot, rust or corrode
Fire-retardant and nonconductive:
Helps create a safer environment
Dimensionally stable:
Won't shrink, swell, warp or bow
Virtually maintenance-free:
Durable and weather-resistant for a longer life cycle
Easy to fabricate and install:
Can be cut, drilled and assembled with standard tools
Non-leaching:
Does not require environmentally hazardous preservatives









Lockable Free Standing Enclosure Box Of Polyester SMC Fiber Glass Material 0Lockable Free Standing Enclosure Box Of Polyester SMC Fiber Glass Material 1Lockable Free Standing Enclosure Box Of Polyester SMC Fiber Glass Material 2Lockable Free Standing Enclosure Box Of Polyester SMC Fiber Glass Material 3
