IP44 Stainless Steel Ielectrical Distribution Box RAL 7035
Product Details
| Material: | Stainless Steel | Color: | White RAL 7035 |
|---|---|---|---|
| Application: | To Protect Circuit Breakers Installed In The Panel Box,Indoor Or Outdoor,Industrial | Type: | Distribution Box,Power Distribution System |
| Protection Level: | IP44 | Standard: | IEC60439-3 |
| Function: | Waterproof Distribution Box | Certification: | CE |
| Working Temperature: | -40 To +50 Degrees Centigrade | Name: | Distribution Cabinet/Power Electric Meter Box |
| Highlight |
IP44 electrical distribution box,Stainless Steel Ielectrical distribution box,RAL 7035 power distribution box |
||
Product Description
Stainless Steel IP44 Grid Connected Power Distro Box
A distribution board (also known as panelboard, breaker panel, electric panel, DB board or DB box) is a component of an electricity supply system that divides an electrical power feed into subsidiary circuits while providing a protective fuse or circuit breaker for each circuit in a common enclosure.
An electrical enclosure is used to protect users from electric shock and electrical or electronic components from the environment. The manufacturers of the electrical enclosure not only concentrate on the safety aspect of it, but also on the attractiveness, to make the enclosure pleasing to the eye. The electrical enclosure can be used to mount switches, displays and knobs. Metals, plastics, stainless steel, carbon steel and aluminum are the materials used to manufacture the electrical enclosure. Customized electrical enclosure can be used for mass-produced equipment and on the other hand, standardized enclosure is used for low production equipment. Electrical enclosure is also used to protect electrical equipment such as transmitters, power distribution systems, power generators, etc.
General:
XL21 type AC low voltage distribution cabinet is suitable for power distribution system with 50Hz AC, rated working voltage 380V, rated working current up to 3150A for power users such as power plants, substations, factories and mining enterprises, as power, lighting and distribution equipment of power conversion, distribution and control. The products are characterized by high breaking capacity, good dynamic and thermal stability, flexible electrical scheme, convenient combination, series, strong practicability, novel structure, high protection level, etc. , the utility model can be used as a replacement product of low-voltage switchgear.
XL21 AC low-voltage distribution cabinet conforms to IEC439"Low-voltage switchgear and control equipment", GB7251"Low-voltage switchgear"and other standards.
| MODE | DIMENSION | MODE | DIMENSION | ||||
| H(MM) | W(MM) | D(MM) | H(MM) | W(MM) | D(MM) | ||
| XL21 2020/15 | 200 | 200 | 150 | XL21 6060/30 | 600 | 600 | 300 |
| XL21 2520/15 | 250 | 200 | 150 | XL21 7050/15 | 700 | 500 | 150 |
| XL21 3020/15 | 300 | 250 | 150 | XL21 7050/20 | 700 | 500 | 200 |
| XL21 3025/20 | 300 | 250 | 200 | XL21 7060/20 | 700 | 600 | 200 |
| XL21 3030/15 | 300 | 300 | 150 | XL21 7060/25 | 700 | 600 | 250 |
| XL21 3030/20 | 300 | 300 | 200 | XL21 7060/30 | 700 | 600 | 300 |
| XL21 3030/25 | 300 | 300 | 250 | XL21 8060/20 | 800 | 600 | 200 |
| XL21 4030/15 | 400 | 300 | 150 | XL21 8060/25 | 800 | 600 | 250 |
| XL21 4030/20 | 400 | 300 | 200 | XL21 8060/30 | 800 | 600 | 300 |
| XL21 4030/25 | 400 | 300 | 250 | XL21 8080/20 | 800 | 800 | 200 |
| XL21 4030/30 | 400 | 300 | 300 | XL21 8080/25 | 800 | 800 | 250 |
| XL21 4040/15 | 400 | 400 | 150 | XL21 8080/30 | 800 | 800 | 300 |
| XL21 4040/20 | 400 | 400 | 200 | XL21 10060/20 | 1000 | 600 | 200 |
| XL21 4040/25 | 400 | 400 | 250 | XL21 10060/25 | 1000 | 600 | 250 |
| XL21 4040/30 | 400 | 400 | 300 | XL21 10060/30 | 1000 | 600 | 300 |
| XL21 5030/15 | 500 | 300 | 150 | XL21 10070/20 | 1000 | 700 | 200 |
| XL21 5030/20 | 500 | 300 | 200 | XL21 10080/20 | 1000 | 800 | 200 |
| XL21 5030/25 | 500 | 300 | 250 | XL21 10080/25 | 1000 | 800 | 250 |
| XL21 5040/15 | 500 | 400 | 150 | XL21 10080/30 | 1000 | 800 | 300 |
| XL21 5040/20 | 500 | 400 | 200 | XL21 10080/40 | 1000 | 800 | 400 |
| XL21 5040/25 | 500 | 400 | 250 | XL21 100100/25 | 1000 | 1000 | 250 |
| XL21 5040/30 | 500 | 400 | 300 | XL21 100100/30 | 1000 | 1000 | 300 |
| XL21 5050/20 | 500 | 500 | 200 | XL21 12060/20 | 1000 | 600 | 200 |
| XL21 5050/25 | 500 | 500 | 250 | XL21 12060/25 | 1000 | 600 | 250 |
| XL21 5050/30 | 500 | 500 | 300 | XL21 12070/25 | 1000 | 700 | 250 |
| XL21 6040/15 | 600 | 400 | 150 | XL21 12080/20 | 1000 | 800 | 200 |
| XL21 6040/20 | 600 | 400 | 200 | XL21 12080/25 | 1000 | 800 | 250 |
| XL21 6040/25 | 600 | 400 | 250 | XL21 12080/30 | 1000 | 800 | 300 |
| XL21 6040/30 | 600 | 400 | 300 | XL21 12080/40 | 1000 | 800 | 400 |
| XL21 6050/15 | 600 | 500 | 150 | XL21 120100/25 | 1200 | 1000 | 250 |
| XL21 6050/20 | 600 | 500 | 200 | XL21 120100/30 | 1200 | 1000 | 300 |
| XL21 6050/25 | 600 | 500 | 250 | XL21 120100/40 | 1000 | 1000 | 400 |
| XL21 6050/30 | 600 | 500 | 300 | XL21 14060/40 | 1400 | 600 | 400 |
| XL21 6060/15 | 600 | 600 | 150 | XL21 14080/40 | 1400 | 800 | 400 |
| XL21 6060/20 | 600 | 600 | 200 | XL21 140100/40 | 1400 | 1000 | 400 |
| XL21 6060/25 | 600 | 600 | 250 | XL21 140100/40 | 1400 | 1000 | 400 |
| More dimension information, please contact with us. | |||||||
