| Product Name: | Solar Combiner Box | Material: | Stainless Steel |
|---|---|---|---|
| Protection Level: | IP65 | Installation Method: | Wall Mounting Type |
| Voltage Protection Level: | 3.8kA | Output Channels: | 1 |
| Max Of Input Channels: | 6 | Application: | Solar Power System |
| High Light: | Solar Array PV Combiner Box,1500V DC Solar PV Combiner Box,3.8 kA Solar PV Combiner Box |
||
1500V DC Solar Array PV Combiner Box Support Customization
PV Combiner Box Advantage
Easy machining with normal tools IP66 Wide operation temperature range Fire Resistance Non-conductive Good resistance to chemical corrosion Light weight Excellent insulating properties Cost-effective material for harsh environment.
High reliability
With DC FUSE
With Surge Protection Device
With DC circuit breaker or DC load isolation switch.
Strong adaptability
IP65 design, waterproof, anti dust and anti ultraviolet.
Strict test for high and low temperature, used widely.
The simple installation, the simplified system wiring, the convenient wiring.
The box body is made of PC cover ABS body , cold rolled steel and other metal materials.
Product Description
.
| Technical Parameters | |||
| Ways(Loops) | 4,6,8,10,12 | ||
| System maximum DC voltage | 1000 | Protection level | IP65 |
| Maximum input current per channel | 1 5A | Output switch | DC circuit breaker (standard) DC rotary isolating switch (optional) |
| Maximum number of input channels | 6 | ||
| Maximum output switching current | 20A/32A | SMC4 waterproof connector | Standard |
| Number of inverter MPPT | N | Photovoltaic DC fuse | Standard |
| Number of output channels | 1 | Photovoltaic DC surge protector | Standard |
| Lightning protection | Monitoring module | Optional | |
| Test category | I pole protection | Anti-reverse diode | Optional |
| Nominal discharge current | 20kA | Box material | metal |
| Maximum discharge current | 40kA | Installation method | Wall-mounted |
| Voltage protection level | 3.8kV | Operating temperature | -25C~+55C |
| Maximum continuous operating voltage | 1050V | Altitude | 2000m |
| Number of poles | 3P | Allow relative humidity | 0~95%, no condensation |
| Structural features | Pluggable module |
|
|
Function
The lightning protection combiner box combines the DC input and sink of the 6-channel photovoltaic module string into one output, each line is equipped with a fuse, and the output is equipped with a lightning arrester and a circuit breaker, which greatly simplifies the DC power distribution cabinet and the reverse Input wiring for the transformer. Provide lightning protection, short circuit protection and grounding protection. The combiner box is divided Into two types. intelligent and non-intelligent. The intelligent lightning protection combiner box is equipped with a flow monitoring unit, which can monitor the current input by each photovoltaic cell string, the summed output voltage, the temperature inside the box, the state of the lightning arrester, and the state of the circuit breaker.
