High Strength DOW UF Membranes SFP-2660 / SFD-2660 For Pretreatment

High Strength DOW UF Membranes SFP-2660 / SFD-2660 For Pretreatment

As a highly efficient water treatment membrane material, the structural characteristics of Dow ultrafiltration membrane have an important influence on the filtration performance and use effect. Below we will analyze the structure of Dow ultrafiltration membrane in detail from three aspects: membrane layer structure, filtration principle and performance advantages.
1. Membrane layer structure
Dow ultrafiltration membrane is usually composed of a multi-layer structure, including a support layer, a transition layer and an active layer. The support layer provides the mechanical strength of the membrane and ensures the stability of the membrane during use; the transition layer plays the role of connecting the support layer and the active layer, while preventing leakage between the membrane layers; and the active layer is the key part of realizing the ultrafiltration function. Its surface is densely covered with micropores, which can intercept impurities such as suspended matter, colloids, and bacteria in the water.
2. Filtration principle
The filtration principle of Dow ultrafiltration membrane is mainly based on size exclusion and adsorption. When water passes through the ultrafiltration membrane, impurities larger than the membrane pore size are retained on the membrane surface, while water molecules and soluble substances smaller than the membrane pore size can pass through the membrane layer. In addition, the active layer on the surface of the ultrafiltration membrane also has a certain adsorption capacity, which can remove some organic matter and heavy metal ions in the water.
3. Performance Advantages
Dow ultrafiltration membrane has many performance advantages in the field of water treatment due to its unique structural characteristics. First, its efficient filtration performance can remove most impurities in the water and ensure the safety and reliability of the effluent water quality; secondly, the ultrafiltration membrane has good mechanical strength and chemical corrosion resistance, and can maintain a stable working state under harsh water conditions; finally, the filtration process of the ultrafiltration membrane does not require the addition of chemical agents, avoiding the generation of secondary pollution.
In short, the structural characteristics of Dow ultrafiltration membrane give it a wide range of application prospects in the field of water treatment. By deeply understanding its membrane structure, filtration principle and performance advantages, we can better grasp the core elements of ultrafiltration technology and provide a strong guarantee for improving water treatment efficiency and water quality safety.

Product Specifications

Figure 1: SFP and SFD 2660 (6-inch diameter)

Figure 2

Operating Parameters

Proper start-up of a UF system is essential to prepare the membranes for operating service and to prevent membrane damage. Following the proper start-up sequence also helps ensure that system operating parameters conform to design specifications so that system water quality and productivity goals can be achieved. Before initiating system start-up procedures, membrane pretreatment, installation of the membrane modules, instrument calibration and other system checks should be completed.

Product Details:

Payment & Shipping Terms:

For application cases, please click:https://www.fgwater.com/Industries/

For detailed parameters, please visit:

SFP-2660	SFD-2660
