DuPont SFP-2880 PVDF Ultrafiltration Module for Drinking Water
Product Details
| SFP-2880 Flow Range: | 3.1 – 9.3 M3 /hr | SFP-2880 Membrane Area: | 77 M² |
|---|---|---|---|
| SFP-2880 Nominal Pore Diameter: | 0.03 µm | SFP-2880 Core Material: | PVDF |
| SFP-2880 Filtrate Flux Of This Model: | 40-120 | Diameter Of This Model: | 8 Inch |
| Product Flow Direction Settings: | External Pressure Structure, Dead End Filtration | Product Max. Operating TMP: | 2.1 Bar |
| Usage: | Surface Water, Seawater,Drinking Water | Adavantage: | Large Flux |
| Highlight |
DuPont PVDF ultrafiltration module,SFP-2880 drinking water filter,ultrafiltration membrane with PVDF |
||
Product Description
The DuPont UF SFP-2880 ultrafiltration module delivers industrial-strength water purification through advanced PVDF hollow-fiber technology. Designed for large-scale applications, it combines maximum filtration area with robust chemical resistance to reduce operational costs and system footprint.
| Attribute | Value |
|---|---|
| Flow Range | 3.1 – 9.3 m³/hr |
| Membrane Area | 77 m² |
| Nominal Pore Diameter | 0.03 µm |
| Core Material | PVDF |
| Filtrate Flux | 40-120 |
| Diameter | 8 inch |
| Flow Direction | External pressure structure, dead end filtration |
| Max. Operating TMP | 2.1 bar |
| Usage | Surface Water, Seawater, Drinking Water |
- Advanced Filtration Performance - Removes bacteria, viruses, and colloids with high efficiency; achieves filtrate turbidity below 0.1 NTU and SDI under 2.5; ideal protection for reverse osmosis systems
- Engineered Durability - Chemical-resistant PVDF membrane withstands extreme pH conditions; U-PVC housing eliminates need for pressure vessels; wide operating temperature range
- High-Efficiency Design - Industry-leading membrane area enables high flow rates; outside-in flow handles high solids loading; reduced backwash frequency lowers water consumption
- Operational Reliability - Consistent performance in municipal and industrial settings; minimal maintenance requirements; compatible with automated control systems
| Parameter | SI Units | US Units |
|---|---|---|
| Filtrate Flux @ 25ºC | 40-120 l/m²/hr | 24-70 gfd |
| Flow Range | 3.1-9.3 m³/hr | 13.6 - 40.9 gpm |
| Temperature Range | 1-40ºC | 34-104ºF |
| Max. Inlet Pressure (@ 20ºC) | 6.25 bar | 93.75 psi |
| Max. Operating TMP | 2.1 bar | 30 psi |
| Max Operating Air Scour Flow | 12 nm³/hr | 7.1 scfm |
| Max Backwash Pressure | 2.5 bar | 36 psi |
| Operating pH Range | 2-11 | |
Proper startup is critical to prevent membrane damage and maintain system parameters within design specifications. Before operation:
- Complete membrane preconditioning and module installation per technical manual
- Calibrate all instrumentation and perform system checks
- Flush the UF system thoroughly to eliminate shipping solution
- Purge residual air from the system
- Start manually at 60% of design capacity
Note: NSF/ANSI 61 certified modules require specific conditioning procedures for potable water production. Check local regulations before use.
FG Water Technologies (part of Wuxi Fenigal Science and Technology Co. Ltd.) specializes in water treatment equipment design, manufacturing, and international shipment. Our product range includes reverse osmosis systems, ultrafiltration, EDI equipment, and more, serving industries worldwide.
For application cases, visit: www.fgwater.com/Industries/
