Veolia E-Cell MK-3 MiniHT EDI module for pharmaceutical ultrapure water production

Veolia E-Cell MK-3 MiniHT EDI module for pharmaceutical ultrapure water production

  • Veolia E-Cell MK-3 MiniHT EDI module for pharmaceutical ultrapure water production
  • Veolia E-Cell MK-3 MiniHT EDI module for pharmaceutical ultrapure water production
Veolia E-Cell MK-3 MiniHT EDI module for pharmaceutical ultrapure water production
Product Details:
Place of Origin: China
Brand Name: VEOLIA
Certification: CE
Model Number: MK-3MiniHT
Document: Veolia EDI catalog.pdf
Payment & Shipping Terms:
Minimum Order Quantity: 1 pc
Price: Negotiable
Packaging Details: standard export packing
Delivery Time: 5- 8 work days
Payment Terms: T/T,Western Union
Supply Ability: 60000 Units per Month
Contact Now
All Products
Lighting Distribution Box (33)
Electrical Distribution Box (33)
Weatherproof Distribution Box (48)
Fiberglass Enclosure Box (60)
ATS Automatic Transfer Switch (68)
EDI Modules (139)
Ultrafiltration Membrane Modules (57)
Industrial Circuit Breaker (85)
Solar PV System (72)
Electric EV Charging Station (21)
Modular Timing Relays (12)
Automation Control Relays (64)
Voltage Regulator Transformer (16)
Film Lighting Balloons (136)
Moon Balloon Light (131)
Tripod LED Balloons (115)
Inflatable Light Tower (62)
Terminal Block Accessories (6)
Detailed Product Description
MiniHT Flow Rate Range Of This Mdoel: 0.5–1.6 M3 /h (2.2–7.0 Gpm) MiniHT Shipping Weight Of This Model: 57 Kg (126 Lbs)
MiniHT Dimensions Of This Model (width X Height X Depth): 30 Cm X 61 Cm X 29 Cm MiniHT Resistivity: ≥ 10 (Pharmaceutical) Or ≥ 16 MOhm-cm (Industrial
Sodium: ≤ 3 Ppb (industrial) Maximum Sanitization Temperature: 85ºC (185ºF)
Maximum Sanitization Inlet Pressure: 2.1 Bar (30 Psi) Application: Pharmaceutical Purified Water

Veolia E-Cell MK-3 Mini HT EDI module for pharmaceutical ultrapure water production
Key Specifications
Flow Rate Range 0.5–1.6 m³/h (2.2–7.0 gpm)
Shipping Weight 57 kg (126 lbs)
Dimensions 30 cm x 61 cm x 29 cm
Resistivity ≥ 10 MOhm-cm (Pharmaceutical) or ≥ 16 MOhm-cm (Industrial)
Maximum Sanitization Temperature 85ºC (185ºF)
Advanced Technology Features
  • Patented HT-EDI™ technology for reagent-grade water production
  • 90% lower energy consumption compared to mixed-bed systems
  • Maintenance-free operation with intelligent control system
  • Real-time monitoring of conductivity, pH, and pressure drop
  • Patented staggered flow channel design prevents scaling
Performance Advantages

Maintains resistivity above 18.2 MΩ*cm with 22% energy reduction compared to traditional EDI equipment. Achieves recovery rates exceeding 90% even with high-hardness raw water.

Available Configurations
  • Basic Unit - Standalone purification
  • RO-EDI Integrated - Complete purification skid
  • GMP Version - With full validation support
Quality Certifications
  • CE, RoHS, CSA and EAC marked
  • FDA-compliant materials
  • UKCA certified
  • Manufactured in ISO 9001 and ISO 14001 facility
  • Halal certified by IFANCA®
Veolia E-Cell MK-3 MiniHT EDI module for pharmaceutical ultrapure water production 0
Technical Parameters
Parameter Value
Inlet Pressure 6.9 bar (100 psi)
Max Temperature 40°C (104°F)
Pressure Drop 1.4-2.8 bar (20-40 psi)
Recovery Rate Up to 93%
Conductivity <117 µS/cm
pH Range 4-11
Applications

Ideal for water for injection, pharmaceutical purified water, and laboratory purified water systems. Complies with USP, EP, and other pharmacopeia standards.

Veolia E-Cell MK-3 MiniHT EDI module for pharmaceutical ultrapure water production 1
Additional Resources

For more information about our EDI technology and application cases, visit FG Water Technologies.

About FG Water Technologies

FG Water Technologies is a high-tech entity specializing in water treatment equipment design, manufacturing, and international shipment. Our products serve various industries including pharmaceutical, food and beverage, chemical, and power.
