| Place of Origin: | China |
| Brand Name: | fenigal/OEM |
| Certification: | CE,CCC etc. |
| Model Number: | NP2B, BP2W, etc. |
| Minimum Order Quantity: | 12pcs |
|---|---|
| Price: | USD1~USD3/unit |
| Packaging Details: | Standard export carton |
| Delivery Time: | 5-8 working days or bulk order negotiate |
| Payment Terms: | T/T, Western Union |
| Supply Ability: | 50,000pcs/month |
| Product Name: | XB2B Push Buttons | Type: | Pilot Device |
|---|---|---|---|
| Control Volt: | 380VAC, 220VDC | Mechanical Life: | 10 Million Cycles |
| Electrical Life: | 300 Thousand Cycles | Environment Temperature: | -15~60 Degree Celsius |
| Contact: | 1 NO / 1 NC Etc. | ||
| High Light: | NP2 Electrical Controls Push Button,Pilot Electrical Control Relay Push Button,24v Controls Push Button |
||
Push Button NP2 Industrial Electrical Controls Illuminated Flush Head 24v 230v 1NO1NC
characteristic
Compliance with IEC, CCC certification standards
IP65, or IP66 (with protective cover)
Operating temperature -25°C to +70°C
Screw fastening method
Complete product range
Modular product design for custom installation and use
Warranty period: 18 months
Advantage
Simple and refined
Rugged and durable metal series for easy operation and quick and easy installation
application
Industry: Machine Manufacturing, Control System Panel Manufacturing, etc.
Downstream applications: transmission and distribution panels, utilities, buildings, airports, etc.
Working & mounting conditions
Electric ratings: AC50/60Hz, AC380V/DC220V;
Degree of protection: IP40
Standard: IEC/EN60947-5-1
2.1 Ambient temperature is -5℃~+40℃, the average temperature during 24 hours couldn't exceed +35℃.
2.2 Altitude: ≤2000m.
2.3 Atmosphere condition: Relative humidity of the atmosphere couldn't exceed 50% when the highest temperature is +40℃; much higher relative humidity is allowable under the condition of lower temperature, for example, when the temperature reaches +20℃, the relative humidity is up to 90%. As for dews, which contingently appear due to change of temperature, special steps should be taken.
2.4 Pollution degree: 3
2.5 Overvoltage category: Ⅱ
Product Series | NP2 |
|---|---|
product type | Button |
Product short name | Pushbutton and Indicators |
Mounting diameter | 22 mm |
Separate sales quantity per piece | 1 |
Signal unit head shape | Round |
|---|---|
Head type | Self reset |
Joystick shape | Red flat head |
Contact type | 1NC/1NO |
Conventional heating current [Ith] | 10 A in accordance with EN/IEC 60947-5-1 |
Rated insulation voltage [Ui] | 600 V (pollution level 3) in accordance with EN/IEC 60947-1 |
Protection process | TC |
|---|---|
Storage ambient temperature | -40...70 °C |
Operating temperature | -25...55 °C |
Product Series | NP2B |
|---|---|
product type | Illuminated button |
Product short name | NP2BW |
Border material | plastic |
Mounting diameter | 22 mm |
Separate sales quantity per piece | 1 |
|---|---|
Protection process | TC |
Operating position | any position |
Mounting pitch | >= 30 x 40 mm (panel) - thickness: 1...5 mm |
Fixed mode | Recommended torque for fixing nut: 2.2 Nm (Us +/- 10 %) |
Signal unit head shape | Round |
Joystick shape | Red flat head |
Contact type | 1 NO |
Contact action | Slow break |
Mechanical life | 1500000 times |
Wiring ability | Bolt fastening, clamping force: <= 1 x 2.5 mm2 |
Tightening torque | 0.8 Nm |
Short circuit protection | 10 A gL fuses in accordance with IEC 60269-1 |
Conventional heating current [Ith] | 10 A |
Rated insulation voltage [Ui] | 600 V in accordance with IEC 60947-4-1 |
Rated impulse withstand voltage [Uimp] | 6 kV in accordance with IEC 60947-1 |
Rated operating current [Ie] | 3 A on 240 V, AC-15, A600 |
Electrical life | 500000 times, AC-15, 3 A on 230 V, working rating <60 times/min, load factor: 0.5 in line with IEC 60947-5-4 |
signal type | Constant |
Light source | LED bulb |
Lamp holder | BA 9s |
Rated power supply voltage [Us] | 220 V AC 50/60 Hz |
Power supply voltage range | 176...242 V communication |
Current consumption | < 20 mA |
Service life | 10,000 hours |
Storage ambient temperature | -40...70 °C |
|---|---|
Operating temperature | -25...55 °C |
Overvoltage type | Class I complies with IEC 536 |
IP protection level | IP65 in accordance with IEC 60529 |
IK protection level | IK03 complies with IEC 60529 |
Standards compliant | GB 14048.5 |
certified product | CCC |
Vibration resistant | 10 gn (f= 40...500 Hz) in accordance with IEC 60068-2-6 |
Impact resistance | 70 gn (duration = 11 ms) for half sinusoidal impact in accordance with IEC 60068-2-27 |
